The Leo is sold as a basic trailer. This basic trailer includes the following:

• Chassis and suspension
  • 3CR12 stainless steel chassis with black marine epoxy coating
  • auto-reverse brake system
  • leaf springs and adjustable safari shock absorbers
  • axle stabilisers
  • 1000kg load capacity
  • heavy-duty tow coupler with safety chain
  • license holder
  • brackets for accessories
• Load containers
  • one main load container
  • all containers with adjustable stainless steel latches and dust proof seals.
• Stabiliser feet to stabilise the trailer when not hooked to a vehicle is standard.

The axle width is matched to that of your tow vehicle and you have a choice of which tyres and rims to fit. Some people prefer to do a complete match with the wheels and rims on their vehicle, others opt for steel rims and the same tyres. It is your choice - the ideal is to make the tyres and rims fully interchangeable with your vehicle.

Leo dimensions:
Basic length	3750 mm
Maximum length with spare wheel	4050 mm
Average width	1810 mm *
Basic height	1500 mm **
Height with single table bracket and tent	1875 mm **
Ground clearance with 16" wheels	360 mm
*   Exact width depends on the vehicle specification
**  Exact height is dependant on the tyre, rims and tent fitted to the trailer
Leo capacity:
Empty weight	470 kg
Loaded weight (max)	1500 kg
Total load	1125 kg
Axle capacity	2500 kg
Total load volume	1733 liter
Rear load door width	1000 mm
Rear load door height	710 mm
Main load door width	800 mm
Main load door height	500 mm
Table door width	530 mm
Table door height	695 mm
Fridge storage box volume	395 liter
Fridge load door width	540 mm
Fridge load door height	560 mm
